High Temperature Heating Cords (HWC)
$130.00
SKU:HWC1120
BriskHeat HWC high temperature heating cords are a multi-stranded resistance wire heating element that are designed for use on small tubes, vessels, or any application where space is limited. Made with a Samox double braided fiberglass outer sheath and rapid thermal response, these cords are flexible, durable and safe to use with electrically conductive surfaces when accurate heat is needed. Ideal for laboratory, R&D, gas tubing, production, maintece, temporary heat, and more.
- 12 ft (3.7 m) length
- 750 Watts
- 120V
Ordering Options:
Quality Guaranteed
Since 1949
Since 1949
Additional Features:
- Exceptional flexibility - can be wrapped around objects as small as 1/8 in (3 mm) diameter
- Rapid thermal response
- Easy to use
- Suitable or high temperatures
Maximum Exposure Temperature:
- Single Installation Use: Up to 932°F (500°C)
- Removable/Reusable: Up to 572°F (300°C)
Construction: Samox
Heater Diameter: 0.19 in (4.8 mm)
Watt Density: 60 W/ft (196 W/m)
Minimum Bend Radius: 0.125 in (3 cm)
IP Rating: IP50
Lead Length: 2 to 6 ft (0.6 to 1.8 m)
Plug Type:
- Built-it split-plug design (120 V)
- Crimped ferrule leads (240 V)
| Part No. 120 VAC | Part No. 240 VAC | Cord Length ft (m) | Total Watts | Lead Length ft (m) |
| HWC1040 | N/A | 4 (1.2) | 266 | 2 (0.6) |
| HWC1060 | N/A | 6 (1.8) | 350 | 2 (0.6) |
| HWC1120 | HWC2120 | 12 (3.7) | 750 | 6 (1.8) |
| HWC1180 | HWC2180 | 18 (5.5) | 1000 | 6 (1.8) |
| HWC1240 | HWC2240 | 24 (7.3) | 1440 | 6 (1.8) |
