Silicone Rubber Heating Tapes (BS0)
$171.00
SKU:BS0101060L
With the flexible design and high temperature capability XtremeFLEXƒ BS0 Silicone Rubber Heating Tapes provide an ideal heating tape solution for both flat and or curved surface heating. Heating tapes can be used on any surface or body requiring fast and efficient direct heating, up to 450F (232C)
- Width and Length: 1 in x 72 in (25 mm x 1830 mm)
- 313 watts
- 120 V
Ordering Options:
Quality Guaranteed
Since 1949
Since 1949
Maximum Exposure Temperature: 450°F (232°C)
Outer Sheath: Silicone rubber extruded
Inner Construction: Fiberglass knitted and braided construction
Minimum Bend Radius: 0.25in (6mm)
Nominal Thickness: 0.125 in (mm)
Power Density: 4.3 watts/in2 (0.7 watts/cm2)
Voltage: 120 or 240 VAC
Power Leads: 2 ft (0.6 m) long with
- 120 VAC Non-Grounded: separable 2-prong plug
- 120 VAC Grounded: Bare Wires
- 240 VAC: crimped ferrule leads or bare wire leads
* See odering information for details
IP Rating: IP66
*CE approved for models with crimped ferrule or bare wire leads
| Width in (mm) | Length ft (m) | Total Watts | Part No. 120 VAC | Part No. 240 VAC | |
| 0.5 (13) | 2 (0.6) | 52 | BS0051020L | BS0052020L** | |
| 4 (1.2) | 104 | BS0051040L | BS0052040L** | ||
| 6 (1.8) | 156 | BS0051060L | BS0052060L** | ||
| 8 (2.4) | 209 | BS0051080L | BS0052080L** | ||
| 10 (3.1) | 261 | BS0051100L | BS0052100L** | ||
| 12 (3.7) | 313 | BS0051120L | BS0052120L** | ||
| 1.0 (25) | 2 (0.6) | 104 | BS0101020L | BS0102020L** | |
| 4 (1.2) | 209 | BS0101040L | BS0102040L** | ||
| 6 (1.8) | 313 | BS0101060L | BS0102060L** | ||
| 8 (2.4) | 418 | BS0101080L | BS0102080L** | ||
| 10 (3.1) | 522 | BS0101100L | BS0102100L** | ||
| 12 (3.7) | 627 | BS0101120L | BS0102120L** | ||
| 14 (4.3) | 731 | BS0101140L | BS0102140L** | ||
| 16 (4.9) | 836 | BS0101160L | BS0102160L** | ||
| 18 (5.5) | 940 | BS0101180L | BS0102180L** | ||
| 20 (6.1) | 1045 | — | BS0102200L** | ||
| 20 (6.1) | 1075 | BS0101200L | — | ||
| 2.0 (51) | 2 (0.6) | 209 | BS0201020L | BS0202020L* | |
| 4 (1.2) | 418 | BS0201040L | BS0202040L* | ||
| 6 (1.8) | 627 | BS0201060L | BS0202060L* | ||
| 8 (2.4) | 836 | BS0201080L | BS0202080L* | ||
| 10 (3.1) | 1045 | BS0201100L | BS0202100L* | ||
| 12 (3.7) | 1254 | BS0201120L | BS0202120L* | ||
| 14 (4.3) | 1463 | BS0201140L | BS0202140L* | ||
| 16 (4.9) | 1627 | BS0201160L | BS0202160L* | ||
| 18 (5.5) | 1881 | BS0201180L* | BS0202180L* | ||
| 20 (6.1) | 2090 | BS0201200L* | BS0202200L* | ||
*Bare Wire, plug not included
**Crimped Ferrule Leads
