Hazardous-Area Silicone Rubber Heating Blankets (SRX)
$762.00
SKU:SRX242414401T3
BriskHeat SRX Series Hazardous Area Silicone Heating Blankets deliver an approved, surface heating solution engineered for large industrial vessels, hoppers, conveyors, silos, and tanks. The SRX design maximizes surface contact to provide uniform thermal distribution, reliable freeze protection, and precise process temperature maintenance in challenging hazardous environments.
- Hazardous-Area Compliance & Safety: Meets NEC 427.23 standards with a 360° grounded heating element and an integrated high-limit thermostat designed to strictly keep blanket temperatures below NEC Article 500 T-ratings.
- Industrial Four-Layer Construction: Built with an extra-thick, multi-layer composite for exceptional mechanical strength and long service life.
- Aggressive Environmental Protection: Engineered to resist moisture, harsh industrial chemicals, and radiation exposure, making them ideal for severe washdown areas and demanding outdoor installations.
- Simplified Surface Installation: Available with optional industrial-strength, pressure-sensitive adhesive backing for fast, secure mounting onto flat or curved metal surfaces.
Ordering Options:
Please complete all selections above to add this item to cart.
$762.00
$657.00
$375.00
$375.00
$311.00
$596.00
$762.00
$375.00
$375.00
$311.00
Quality Guaranteed
Since 1949
Since 1949
Power Density: 2.50 W/in² (0.39 W/cm²)
Voltage: 120 or 240 VAC, 12 or 24 VDC
Exposure Temperature: -60°F to 400°F (-51°C to 204°C)
Nominal Thickness: 3/16 in (4.8 mm)
Dielectric Strength: Over 2000 volts
Silicone Rubber Density: 104 oz/yd² (3526 g/m²)
Power Cord: 12 in (305 mm) long high temperature leads with silicone rubber protective sheath
Conduit Connection: Female 3/4-14 NPSM conduit fitting
IP Rating: IP54
Approvals:
Zone 2/22
Class I Division 2 Groups A, B, C, and D
Class II Division 2 Groups F and G
Requires conduit installation for hazloc installations
Zone 2/22
Class I Division 2 Groups A, B, C, and DClass II Division 2 Groups F and G
Requires conduit installation for hazloc installations
Viscosity and temperature control
Freeze protection
Storage tanks
Hoppers
Enclosures/control panels
Silos
Conveyors
Presses
Vats
Tank trucks
Low-temperature ovens
Battery warming
Medical device heating
Composite curing
| Width in (mm) | Length in (mm) | Total Watts |
| 6 (152) | 12 (305) | 180 |
| 6 (152) | 24 (610) | 360 |
| 12 (305) | 12 (305) | 360 |
| 12 (305) | 24 (610) | 720 |
| 24 (610) | 24 (610) | 1440 |
Catalog/Specifications Sheet
Instruction Manuals
-
SRX Extra Heavy-Duty Hazardous-Area Silicone Rubber Heating Blankets - Instruction Manual Hazardous Area Silicone Rubber Heating Blankets SRX Instruction Manual
Q: What are silicone rubber heating blankets used for?
A: Silicone rubber heating blankets are commonly used to:
- Prevent freezing of equipment and materials
- Maintain process temperatures
- Reduce the viscosity of oils, resins, adhesives, and other fluids
- Heat tanks, vessels, drums, pipes, and composite materials
- Support laboratory testing and research applications
Q: How do I select the right silicone rubber heating blanket?
A: Key factors include:
- Surface dimensions
- Material being heated
- Desired temperature
- Ambient conditions
- Available voltage
- Required wattage
- Control requirements
Q: Can silicone rubber heating blankets be customized?
A: Yes. Custom silicone rubber heating blankets can be manufactured in various sizes, shapes, voltages, wattages, and temperature ranges.
Q: Can silicone rubber heating blankets be used outdoors?
A: Silicone rubber heating blankets are moisture and chemical resistant, but you should always check the rating in the specifications of the product before using outdoors.
Q: Are silicone rubber heating blankets flexible?
A: Yes. Silicone rubber heating blankets are highly flexible and can conform to flat, curved, and irregular surfaces. This flexibility helps provide efficient heat transfer and even temperature distribution.
Q: How are silicone rubber heating blankets installed?
A: Installation methods vary by model and may include:
- Pressure-sensitive adhesive backing
- Spring systems
- Hook-and-loop fasteners
Q: Are silicone rubber heating blankets energy efficient?
A: Yes. Because they transfer heat directly to the target surface, silicone rubber heating blankets can be an energy-efficient heating solution compared to heating an entire room or enclosure.
Q: Can silicone rubber heating blankets be used for composite curing?
A: Yes. Silicone rubber heating blankets are widely used in composite repair and curing applications, providing controlled and uniform heat for aerospace, marine, automotive, and industrial composite processes.
Q: Is a control needed for this product?
A: Yes, you will need the use of a temperature control for this product unless the product states that it comes with a control.
Q: What’s the largest size blanket you can manufacture?
A: We currently manufacture blankets of any length with a maximum width of 4 feet (1.2 m).
Q: Can you change the setpoint on a high limit thermostat on SRX heaters?
A: No, the setpoints are designed to keep the blanket rated for hazardous area approvals. Any changes will void the approvals.
Q: How do I hold the heater in place until I can get the PSA cured?
A: We suggest using a high-heat adhesive tape to secure the heater to its vessel until the PSA has had time to properly cure. A good general guideline for curing is 200°F (93°C) for 20 minutes.
Q: Can I leave the tape on after the PSA is cured?
A: You may if it is rated for the temperatures you are wanting to achieve in your process.
